产品规格 |
单位 |
HXYD260 |
||||||||
合模单元Clamping Unit |
|
|||||||||
合模力Clamping force |
kN |
2600 |
||||||||
移动模板行程Moving mould-plate stroke |
mm |
530 |
||||||||
最大模厚 Max.Mould height |
mm |
600 |
||||||||
最小模厚Min.Mould height |
mm |
230 |
||||||||
拉杆有效间距 Space between tie-bars |
mm |
610*560 |
||||||||
液压顶出力Hydraulic ejector force |
kN |
87 |
||||||||
液压顶出行程 Hydraulic ejector stroke |
mm |
150 |
||||||||
顶出点数Ejector number |
n |
13 |
||||||||
注射单元Injection Unit |
I650 |
I900 |
I1000 |
|||||||
螺杆直径Screw diameter |
mm |
40 |
45 |
50 |
45 |
50 |
55 |
50 |
55 |
60 |
螺杆长径比Screw L/D ratio |
L/D |
22 |
20 |
20 |
22.2 |
20 |
20 |
22 |
20 |
20 |
理论注射容积Injection capacity in theory |
cm3 |
263 |
334 |
412 |
381 |
471 |
570 |
471 |
570 |
678 |
注射重量Injection weight(ps) |
g |
240 |
303 |
375 |
347 |
428 |
518 |
428 |
518 |
617 |
注射压力Injection pressure |
MPa |
2531 |
2000 |
1620 |
2469 |
2000 |
1653 |
2178 |
1800 |
1513 |
注射速度Injection velocity |
mm/s |
350 |
350 |
350 |
||||||
塑化能力 Plasticizing capacity |
g/s |
30 |
42 |
50 |
42 |
50 |
60 |
50 |
60 |
75 |
螺杆转速 Screw speed |
rpm |
400 |
400 |
400 |
||||||
其他Other |
|
|||||||||
油泵压力Pump pressure |
MPa |
17.5 |
||||||||
驱动功率 Motor/Driving power |
kW |
37(注)+23(熔)+30(油) |
37(注)+23(熔)+30(油) |
37(注)+23(熔)+30(油) |
||||||
加热功率 Heating capacity |
kW |
13.55 |
13.55 |
16.83 |
||||||
外形尺寸 Machine dimension |
m |
7.04*1.57*2.01 |
7.04*1.57*2.01 |
7.04*1.57*2.01 |
||||||
机器重量 Machine weight |
t |
9.7 |
10 |
10.2 |
||||||
油箱容积 Oil tank capacity |
L |
412 |
